FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment

FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment

  • FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
  • FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
  • FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
  • FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
  • FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
  • FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment
Product Details:
Place of Origin: Jiangsu, China
Brand Name: changier
Payment & Shipping Terms:
Price: $38.00 - $200.00/pieces
Packaging Details: carton packing
Supply Ability: 1000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Applicable Industries: Food & Beverage Shops, Energy & Mining, Food & Beverage Factory, Hotels Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Other Warranty Of Core Components: 3 Months
Core Components: Pressure Vessel Weight: 15 Kg, As Demand
Warranty: 3 Years Color: White
Vessel Diameter: 8inch Usage: For RO Membrane
Port: Side Port ,end Port Working Pressure: 300psi,450psi,1000psi
Application: Sewage Treatment Length: 1-7 Element
Operating Temperature: -7℃-49℃ Port: Any Port Of China

FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment

FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 0



8" RO membrane Housing

The integrated locking ring thrust ring can reduce pressure drop at high-speed flow rate. Its cone design can guarantee high compression resistance property. The maximum may reach to 205kgf/cm2. The surface is polyurethane coating. It can protect that the membrane housing cannot be suffered from environmental damage and assure its beautiful and taste appearance. The standard color is white. Other color may also be provided.

FEATURES & BENEFITS

  • Mirror finish inner surface for easy and quick loading and unloading of membranes
  • Quick lock head retention system for quick access to membranes
  • Exteriors coated with high-gloss polyurethane paint for UV resistance
  • Compatible for using in brackish, high brackish and sea water applications for respective pressure ratings
SPARE PARTS OVERVIEW



Material FRP(fiberglass)
Pressure 300/450/600/1000/1200psi
Connection type Side Port/end Port
Element 1
Hydraulic test 100% tested before delivery
Packing Carton
Color White
Size 4Inch
Application RO System
Water Outlet 1/2" or 3/4"


FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 1

 FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 2 FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 3 FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 4 FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 5

FRP Membrane Housing 8040 FRP Pressure Vessel For Sea Water Treatment 6
