Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T

Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T

  • Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T
  • Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T
  • Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T
  • Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T
  • Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T
Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T
Product Details:
Place of Origin: Jiangsu, China
Brand Name: cangier
Payment & Shipping Terms:
Price: $10,000.00 - $12,000.00/sets
Packaging Details: wooden package and container
Supply Ability: 10 Set/Sets per Month
Contact Now
Detailed Product Description
Applicable Industries: Farms, Construction Works , Manufacturing Plant, Fishery Condition: New
Ice Shape: ICE BLOCK Voltage: 380V/220V
Power: 3000W Dimension(L*W*H): 4600mm*1790mm*2130mm
Weight: 3500 KG Warranty: 1 Year
Key Selling Points: High Productivity Ice Storage Capacity: 1000kg
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Marketing Type: Hot Product 2022 Warranty Of Core Components: 1 Year
Core Components: PLC, Pump, Motor, Compressor Compressor Brand: Bitzer, Copeland
Application: Industrial After Warranty Service: Online Support And Video Technical Support
After-sales Service Provided: Engineers Available To Service Machinery Overseas Ice Block: 5/10/25/50 Kg
Refrigerant: R22 Or R404a Or R507 Cooling Way: Cooling Way
Ice Freezing Time: 6Hours Evaporator For Ice: Aluminum Plate
Machine Size: 4600mm*1790mm*2130mm Ice: Sanitary, Clean And Edible
Widely Used: For Seafood Cooling Port: Shanghai
High Light:

Refrigerators Ice Block Machine 2T

,

R404a Ice Block Machine

2T Block Ice Machine  Making For Refrigerators  ice block machine direct cooling commercial type



Overview of direct cooling block ice machine:
The direct cooling block ice machine uses high-efficiency heat-conducting alloy aluminum as the evaporator. The refrigerant flows from bottom to top in the flow channel of the aluminum plate (hot-extruded hollow alloy aluminum plate), and exchanges heat with the water in the aluminum plate grid, so that the Water freezes. The direct cooling block ice machine has strong integrity, is easy to install, easy to move, and fully meets the requirements of environmental protection. The condensing system of Bingma's direct cooling block ice machine is mainly based on evaporative cooling and air cooling, and does not use water cooling system. According to the needs of customers, we can also configure the automatic ice pushing device for the machine.

Features:
1. Small footprint, one-time ice output, saving labor and time;

2. Fully automatic ice making, melting and de-icing process with high efficiency;

3. Modular design, convenient on-site installation and convenient later movement;

Applicable industries:
1. When the water quality reaches the edible standard, edible ice can be produced;

2. The occasions where salt water ice cubes cannot be used;

3. Ice used for ice sculptures and ice exhibitions;

4. Meat processing plants, live poultry slaughter plants, seafood processing;

5. Mine cooling, factory cooling;

6. Ice for chemical industry.

Faster ice Block Making but Lower power consumption

Aluminum evaporator is of 3 times higher heat exchange efficiency than other steel [SUS304, galvanized steel], so ice block can be completely frozen faster. In this way, it can produce more ice blocks with lower power consumption

Clean ice Block Making

cangier all DK series ice block machine can make ice block directly without via brine and any other pollution, so it can produce clean ice blocks even for human consumption.

Longer service life Lower future investment

Without salt and other material's corrosion, cangier all DK series ice block machine with longer service life and you need just clean the ice moulds/ice machine regularly. The the fucture maintenance  investment is lower.

Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 0
Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 1





Space Requirement

For ice making is faster than traditional brine type ice block machine, same capacity, our DK series ice block machine take less space than the brine type ice block machine



True Eco-friendly

DK series ice block machine don't need salt water for ice block making, also it won't produce any pollution to the environment


Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 2

Labor saving

Add water-ice making-wait-ice dropping and ice block moving away. DK series ice block machine need only your labor cost to move the ice blocks, all other process is automatically finished.

Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 3Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 4

DK50 ice block machine

Water cooled with cooling tower design

√ Fast Installation

√ Space saving

√ Easy operation

√ Labor saving

√ Fast ice block making speed

√ Edible ice block making

√ Low energy consumption

√ Low maintenance cost

water cooing system
One button start and one button ice block harvest
All ice blocks can be harvest at once, the ice bed can be pull out easily

Other Merit as below:

1,  The aluminum is lighter than the steel, so we can move the direct cooled ice block machine easily.
2,  The direct cooled ice block machine can be designed into containerized type as well.
3. The ice block eight we can do 10kg  20kg, 25kg, 50kg per pcs on our direct ice block machine. The ice making time is decided by the ice block thickness. Ice block machine DK50 design is different according to the ice block weight.

Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 5

Working conditions

◆ Refrigerant: R22/R404A
◆ Supply Power: 380V~420V, 50Hz/60Hz, 3P; 220V~240V, 60Hz, 3P; 440V~480V, 60Hz, 3P;
◆ Working Conditions: Input Water Temp: 21℃; Evaporating Temp:- 15℃; Condensing Temp: 40℃;
(Notice: the actual ice production will be changed with input water temp and ambient temp.)
◆cangier reserve the final explanation to the products technique parameter, model and specifications can be subject to change without notice.

ABOUT cangier COMPANY

cangier Profile

1. Established in 2004,jiangsu cangier Refrigeration Equipment Co., Ltd is an integrated manufacturer, specialized in the research, design, manufacture and sale of refrigeration equipments.

2. cangier has more than 30,000 square meters for the factory production space, more than 300 employees, including senior technical R & D team and professional sales team.

3. cangier brand products have popularly sold in Europe, Australia, Southeast Asia, Middle East, Africa, South America and South Pacific Islands. cangier has become a famous refrigeration enterprise in China, and a famous brand name with international recognition and reputation.

cangier Products
Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 6
Our main products include: brine water ice block machine from 1 ton to 100 tons daily production, large edible ice cube machine, commercial ice maker, tube ice machine, plate ice machine, fresh water flake ice machine, sea water flake ice machine, direct cooling ice block machine, automatic conveying system, cold room, ice crusher machine, low temperature water chiller, automatic packing system, and other series of ice making equipments.

cangier Advantage

Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 7Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 8


1. We has passed ISO9001,CE,SGS,TUV and some other certificates.

2. We has become the partner of Beijing Olympic Games in 2008,Shanghai World Expo in 2010,Guangzhou Asia Games in 2010 and London Olympic Games in 2012.



Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 9
Certifications

Our Service
Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 10

INSTALLATION SERVICE

* FREE INSTALLATION

* OPERATION AND MAINTENACE TRAINING

* ALL RELATED PRODUCT SUGGESTION FOR A ICE FACTORY



ONE YEAR WARRANTY

* ONE YEAR WARRANTY FOR ALL PARTS QUAILY ON OUR ICE MACHINE

* CANGIER AFTERSALES 24 HOURS AVAILABLE

Industrial Refrigerators Ice Block Machine Direct Cooling Commercial 2T 11
FAQ

A. Installation for ice machine:
1). Installing by the user: we will test and install the machine before shipment, all necessary spare parts, operation manual and video are provided to guide the installation.
2).Installing by cangier engineers:
   (1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user should provide accommodation and round-trip ticket for our engineer.
   (2) Before our engineers' arrival, the installation place, electricity, water and installation tools should be prepared. Meanwhile, we will provide you a Tool List with the machine when delivery.
   (3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.
   (4) 2~ 3 workers are required to assist the installation for big project.
   (5) Any delay due to customer's reason, it will be charged from the 8th day, USD100/day for one person as installation fee. Free of charge for one week.

B. Warranty:
1) 12 months warranty after delivery.
2)Professional after-sales department to provide 24/7 technical support, all complaints should be replied within 24 hours.
3)Over 10 engineers available to service machinery overseas.
4)Free spare parts replacement within warranty period.
5)Beyond guarantee period, we will charge market price for spare parts.

Any other question, please leave your meaasage below, our salesman will reply you immediately.


1. Questions before quotation

A. Would you make ice from seawater, saltwater or freshwater?

B. Where and when would the machine be installed roughly?The ambient temperature and water inlet temperature?

C. What's the power supply?

D. What is the application of the flake ice produced?

E. Which cooling mode would you prefer to? Water or air ,Evaporative cooling?



2. Installation & commissioning

A. Installed by customers according to the manuals, online instructions and live video conference of cangier.

B. Installed by cangier engineers.

C. cangier would arrange 1~3 engineers based on the projects to the installation sites for the final supervision of all installations and commissioning.

D. Customers need to provide local accommodation and round-trip ticket for our engineers and pay for the commissions. US Dollars 100 per engineer per day.

E. Power, water, installation tools and spare parts need to be ready before cangier engineers arrive.



3. Warranty & Technical support

A. 1 year after Bill of Lading date.

B. Any failure occurred within the period due to our responsibility, cangier will supply the spare parts for free.

C. cangier provide full technical support and training courses after equipment installation and commissioning.

D. Permanent technical support & consultation all life long for the machines.

E. Over 25 engineers for instant after-sale services and more than 15 are available for serving overseas.

365 days X 7 X 24 hours phone / EMAIL assistance



5 Failure Claim procedures

A. Detailed written failure description is required by fax or by mail, indicating the relevant equipment information and detailed description of failure.

B. Relevant pictures are required for failure confirmation.

C. cangier engineering and after-sales service team will check and form a diagnosis report.

D. Further trouble-shooting solutions will be offered to customers within 24 hours after receiving the written description and pictures
