Stainless Steel Shaftless Screw Conveyor Machine Industrial Low Noise

Stainless Steel Shaftless Screw Conveyor Machine Industrial Low Noise

Stainless Steel Shaftless Screw Conveyor Machine Industrial Low Noise
Stainless Steel Shaftless Screw Conveyor Machine Industrial Low Noise
Product Details:
Place of Origin: Jiangsu,China
Brand Name: Changier
Certification: CE/ISO9001
Model Number: CG-SS-002
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: 45 Weeks
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Units Per Year
Contact Now
Detailed Product Description
Voltage: Customerized Dimension(L*W*H): Customized Size
Warranty: 1 Year Warranty Application: Industry Use
Structure: Conveyor System Certification: ISO 9001, CE Certificate
High Light:

shaftless screw conveyor


screw feeder machine



Compared with traditional shaft screw conveyor, Shaftless screw conveyor adapts to non center shaft design, using a flexible steel spiral push material, which has the following advantages: strong anti winding. The spiral surface of fully enclosed transmission and easy cleaning, can ensure the sanitation and the material is not contaminated, no leakage, high torque, low energy consumption. Due to the fact that the screw is not provided with a shaft, the material is not easy to be blocked, the discharge port is not blocked, and the utility model can be operated at a lower speed, and the utility model has the advantages of smooth transmission and low energy consumption. The machine can work under high temperature. The utility model has the advantages of compact structure, space saving, beautiful appearance, convenient operation, economy and durability.





Shaftless screw conveyor is used for screening disposal from local sewage treatment plant, sewage pre-treatment device in the residential zone, and municipal storm- rain purmp station/ sewage purmp station as well as waterworks and so on. It is mainly used togother with such equipment a8 screen or dewaterer and 80 on to transport the screening or dewatered sludge.


Structure & operating principle

Applied with shaftless screw type. When the material enters in the material-incoming hopper of conveyor,the material is pushed to move and slide depending on the rotation of helical blade. The material is conveyed to the discharging port along the U-shaped conveying chute and this equipment is used together with squeezer or trash trolley to handle the material further.


For drive unit, the axially-installed parallel axis bevel-gear reducer is used. The structure is compact and the operation is safe and smooth.The conveyance direction is determined by both helical direction of helical blade and rotating direction of motor. The two-way conveyance can be realized.

The inner liner is installed in the U- -shaped chute and it has such advantages as strong wear-resisting property and long service life as well as easy replacement.

The framework of conveyor is fixed by expansion bolt without embedded This equipment can be used together with corollary equipment for gang control. Therefore, the control is convenient. It also can be equipped with local control box .

Stainless Steel Shaftless Screw Conveyor Machine Industrial Low Noise 0
